Fuel injection is used to ensure excellent fuel efficiency as well as environmental friendliness.
The two components of the fuel injection mechanism used in YZF-R15 version 2.0, a) the sensors that gather information on the engine’s operation, and b) the fuel supply system that supplies gasoline, have both been designed to be lightweight and simple. The sensor component uses only 4 sensors (Red blinking points) to gather large amounts of information relating to engine operations, which is sent to a small 26-pin ECU, which in turn calculates the optimum fuel supply. The fuel supply component consists of a small, fuel pump, modularized regulator and filter, and a small injector, all of which come together to enable a lightweight, compact form. The injector injects finely atomized spray of fuel through 6 hole type injectors.
In order to maximize the efficiency of the fuel injector, which injects the optimum amount of fuel for different amounts of intake air, YZF-R15 version 2.0 is equipped with a large 3-liter air cleaner. The duct area of the intake duct was designed optimally to optimize the flow of intake air.
Additionally, the use of a 4-valve combustion chamber (a combustion chamber with 2 intake and exhaust valves each) has allowed designers to layout the spark plug at the center of the combustion chamber for better flame propagation. This also increases the total valve area relative to the 2-valve chambers for improved intake/exhaust efficiency (volumetric efficiency). YZF-R15 version 2.0 is fitted with a hemispherical 4-valve combustion chamber, a configuration that allows intake and exhaust valves to be laid out in the smallest size possible.
In addition, the intake and exhaust valve angles have been kept small to achieve optimum combustion chamber configuration. We also aimed at minimizing the surface area/volume ration (S/V ratio) in the combustion chamber, which is key to improving fuel efficiency. In conjunction with the fuel injection system, this combustion chamber contributes to comfortable riding during long-distance rides as well as during medium to high-speed riding.
YZF-R15 version 2.0’s engine delivers excellent response, fuel economy, is environmentally friendly and a comfortable ride.
